Lazy Line Painter 是基于 Raphaël(一个用于在网页中绘制矢量图形的 Javascript 库)的 jQuery 路径动画插件,能够把线条图案转换为吸引眼球的路径动画模式。
使用方法
使用这个插件被分层成两部分,准备你的Web友好的数据和配置。
1、准备你的SVG数据
在你选择的矢量编辑器创建您的生产线的艺术,首先在 Illustrator 中把线条图形导出为 SVG 格式,要确保图案不填充,没有封闭路径,线条要有明显的开始和结束点,类似画板绘制的图案;
2、配置选项
一些属性可以设置之前,线描画, 这些;
'strokeWidth' // Adjust width of stroke 'strokeColor' // Adjust stroke color 'strokeCap' // Adjust stroke cap - butt | round | square 'strokeJoin' // Adjust stroke join - miter | round | bevel 'strokeOpacity' // Adjust stroke opacity 0 - 1 'onComplete' // Callback fired after animation finishes 'onStart' // Callback fired just before animation starts 'delay' // Delay before animation starts 'overrideKey' // Set this property if you selector id doesn't match the key referencing your path data value within svgData. 'speedMultiplier' // slow down or speed up the animation 'drawSequential' // true: draw each path sequentially, false, draw all at once 'reverse' // reverse drawSequence 'responsive' // true: responsive width and height
然后把导出的 SVG 文件拖放到 Lazy Line Painter 转换器中,拷贝生成的 JavaScript 代码;
3、最后在页面中引入 jQuery、Raphaël & Lazylinepainter,粘贴之前拷贝的代码到 DOM Ready 方法中。
使用这些选项你的元素的画前,通过lazylinepainter对象作为参数包含您希望变更attritubes;
$('#demo').lazylinepainter({ 'svgData' : svgData, // the object containing the SVG path info 'strokeWidth':7, 'strokeColor':'#de8f8f' } )
注:唯一需要的是对象(其中包含您svgdata路径信息)。其结构应 svgdata对象这样的插件能够。
var svgData = { 'demo' : // name of your lazy line { 'strokepath' : // this contains all your SVG path info [ { 'path': "M144.869,199c0....", // path string , 'duration':300, // time taken to animate that path 'strokeColor':'#000000', // stroke color can be set individually 'strokeWidth':3 // stroke width can be set individually 'reverse': true // reverse stroke individually }, { 'path': "M155.85,29c0...." 'duration':1000 }, { etc ... ], 'dimensions' : // dimensions of element { 'width': 270, 'height':266 } } }
API参考
Paint
Animate path
$('#demo').lazylinepainter('paint');
Erase
Clear path – paint can still be called on the element after it has been erased;
$('#demo').lazylinepainter('erase');
Pause / Resume
pauseResume path animation
$('#demo').lazylinepainter('pauseResume');
Destroy
Remove path – removes lazyline data and element from DOM;
$('#demo').lazylinepainter('destroy');
